InformazioniZF GASKET AND SEAL KIT FOR ZF 3M, 5M, HURTH HBW 35 & HBW 50 GEARBOXES
KIT FRIZIONI IL KIT INCLUDE:
SEALING RING 1 0634502009 SHIFT COVER
O-RING 1 0634306179 SHIFT FORK SHAFT
SEALING RING 2 3306301016 DRAIN PLUG/OIL DIPSTICK
GASKET 4 3304301015 COVER
GASKET 1 3306301015 SHIFTINF COVER
SEALING RING 1 0634301830 INPUT SHAFT
SEALING RING 1 0634300371 OUTPUT SHAFT
THRUST WASHER 2 0501336515 BEARING/GEAR
INNER CLUTCH DISC 4 3304304040 CLUTCH PACK
OUTER CLUTCH DISC 4 3304304021 CLUTCH PACK
SPRING 3 3306304024 DISC CARRIER
KEY 1 0631501634 OUTPUT SHAFT
SHIM 0.15 MM 2 3304304029 CLUTCH PACK
SHIM 0.20 MM 2 3304304030 CLUTCH PACK
SHIM 0.30 MM 2 3304304031 CLUTCH PACK
SHIM 0.40 MM 2 3304304032 CLUTCH PACK
SHIM 0.50 MM 2 3304304033 CLUTCH PACK
SHIM 0.40 MM 2 3304304032 INPUT + OUPUT SHAFT
SHIM 0.50 MM 2 3304304033 INPUT + OUPUT SHAFT
